1.產品簡介

DE3KM17B系列  是我公司專門為純電動汽車量身打造的一款大功率、小體積 DC/DC 變換器。

變換器具有超寬的輸入范圍，可工作在輸入電壓 200Vdc 至 950Vdc 之間，解決了不同車型需選用多種

DC 變換器的困擾，避免重復設計，達到通用化、模塊化的目的；

采用數字化處理技術，自帶 CAN 通訊，能夠向 CAN 總線上報數據，同時接受 CAN 總線的開關機

命令，可實時控制和監測 DC 變換器工作狀態。

DE3KM17B-650S28RC is a high-power, small-volume DC/DC converter specially designed for pure

electric vehicles. The converter has an ultra-wide input range, and can work between input voltage

of 200Vdc to 950Vdc, which solves the trouble of choosing a variety of DC converters for different

models, avoids repeated design, and achieves the purpose of generalization and modularization.

It adopts digital processing technology and has its own CAN communication, which can report data

to CAN bus, and at the same time accept the switch command of CAN bus, which can control and

monitor the working status of DC converter in real time.

輸出電壓：14Vdc & 28Vdc & 48Vdc

Output Voltage

保護功能/ Protection

輸出過流保護/Output Current Limited Protect

輸出短路保護/Output Short Circuit Protection

輸出過壓保護/Output over Voltage Protect

輸出欠壓保護/ Output under Voltage Protect

輸入過壓保護/ Input over Voltage Protection

輸入欠壓保護/ Input under Voltage Protection

過溫保護/Over Temperature Protect

CAN 通信故障/CAN Communication Fault

報通訊故障不關機，CAN 通訊恢復正常后，取消報通

訊故障。

does not shut down when it reports communication failure.

After CAN communication returns to normal, the

communication failure report will be canceled.

工作環境溫度： -30℃～+60℃

Working

貯存溫度  -40℃~+105℃

Storage

工作濕度 5％～85％RH（不冷凝） (Non-condensing)

Working

冷卻方式：風冷/Air Cooling

Cooling Method

IP防護等級：IP66

IP Protection Grade

耐振動性能：3.12 in QC/T 413-2002 (other parts)

Vibration Resistance

重量/Weight：≤6Kg±0.5kg

DC直流轉換器廣泛應用：新能源乘用車、新能源商用車、新能源工程機械車、

                                          新能源叉車、   新能源牽引車、  移動儲能車、

                                          AGV以及光伏和其他儲能換電設備。

DC DC converters are widely used in new energy passenger vehicles, new energy commercial vehicles, new energy construction machinery vehicles, new energy forklifts, new energy tractors, mobile energy storage vehicles,

 AGVs, photovoltaic and other energy storage and power exchange equipment.
