1.產品簡介/Product introduction

DE1K8S20 是我公司專門為純電動汽車量身打造的一款大功率、小體積 DC/DC 變換器。變

換器具有超寬的輸入范圍，可工作在輸入電壓 200Vdc 至 950Vdc 之間，解決了不同車型需選用多種 DC 變

換器的困擾，避免重復設計，達到通用化、模塊化的目的；采用數字化處理技術，自帶 CAN 通訊，能夠

向 CAN 總線上報數據，同時接受 CAN 總線的開關機命令，可實時控制和監測 DC 變換器工作狀態。與國

際一流汽車電源廠商完全同步，各項性能指標已達到或超越國際同行水平，無故障運行時間

更長。該系列電源也可適用于需要恒壓、恒流電源的各個領域。

DE1K8S20  is a high-power, small-volume DC/DC converter specially designed for pure electric

vehicles . The converter has wide input voltage range and of 200Vdc to 950Vdc, solving the problem of choosing

multiple DC converters for different vehicle type, avoiding repeated design and achieving the purpose of

generalization and modularization;It adopts digital processing technology, with CAN communication, able to

report data to CAN bus and accept power on command of CAN bus at the same time, monitoring the working

status of DCDC converter in real time. Synchronizing with the world-class automobile manufacturers,

the performance indicators have reached and even exceeded the international peer level, with longer

fault free operation time, can be also applied to field needing constant voltage and constant current

field.

額定功率:1800W

Rated Power

輸入電壓范圍：200V~950Vdc

Input Voltage Range

輸出電壓：14Vdc & 28Vdc & 48Vdc

Output Voltage

IP防護等級：IP67

IP Protection Grade

冷卻方式：風冷/Air Cooling

Cooling Method

重量/Weight：≤3.3Kg±0.5kg

輸出過流保護/Output Current Limited Protect

輸出短路保護/Output Short Circuit Protection

輸出過壓保護/Output over Voltage Protect

輸出欠壓保護/ Output under Voltage Protect

輸入過壓保護/ Input over Voltage Protection

輸入欠壓保護/ Input under Voltage Protection

過溫保護/Over Temperature Protect

CAN 通信故障/CAN Communication Fault

連續 5s 未收到指令,DC報通訊故障不關機，CAN 通訊恢復正常后，取消報通訊故障。

No command receivedfor 5 consecutive seconds

does not shut down when it reports communication failure.

After CAN communication returns to normal, the

communication failure report will be canceled.

工作環境溫度Working: -30℃～+60℃

貯存溫度:  -40℃~+105℃

Storage

工作濕度:5％～85％RH（不冷凝） (Non-condensing)

Working

耐振動性能：3.12 in QC/T 413-2002 (other parts)

Vibration Resistance

DC直流轉換器廣泛應用：新能源乘用車、新能源商用車、新能源工程機械車、

                                          新能源叉車、   新能源牽引車、  移動儲能車、

                                          AGV以及光伏和其他儲能換電設備。

DC DC converters are widely used in new energy passenger vehicles, new energy commercial vehicles, new energy construction machinery vehicles, new energy forklifts, new energy tractors, mobile energy storage vehicles,

 AGVs, photovoltaic and other energy storage and power exchange equipment.
